Economy quality description

The Economy wooden window is a practical and cost-effective solution for garden buildings, summerhouses, and cabins, available for 28 mm and 44 mm wall thicknesses.

Key Differences: 28 mm vs. 44 mm-68mm versions

• 28 mm version: Supplied with single 4 mm glass, ideal for lightweight, non-insulated structures.
• 44 mm - 68 mm version: Includes double glazed unit (4-10Ar-4GNP) for enhanced insulation and weather resistance.
• 28 mm version: double door width 1,4m.
• 44 mm - 68 mm version: double door width 1,6m

Note: This window model is not suitable for walls thicker than 68 mm and is not recommended for use in insulated or twinskin wall constructions.

Technical Specifications

• Wall compatibility: 28 mm, 44 mm, 58mm or 68mm
• Glazing:
  • Single glazing (4 mm glass) for 28 mm wall
  • Double glazing (4-10Ar-4GNP) for 44 mm - 68mm wall
• Frame material: Solid pine
• Opening type: Side-hinged with manual tilt function
• Handle: Economy silver-tone window handle
• Sealant: Silicone for weather protection
• Drip cap: Wooden profile mounted above sash
• Locking system: Manual leaf locking latch (bottom)
• Included accessories: Detachable wooden glazing bars

Optional Features

• Tempered (safety) glass for enhanced security

Important Recommendation: All wooden parts of the windows and doors must be covered with a high-quality waterproof paint immediately after house assembly—both from the interior and exterior sides. This ensures proper protection and longevity of the wood components.
